Industrial Spray & Baking Chamber Specifications
| Component Category | Configuration & Technical Parameters |
| Interior Work Space | 15,000 mm (L) × 5,000 mm (W) × 5,000 mm (H) |
| External Footprint | 15,130 mm (L) × 6,890 mm (W) × 5,600 mm (H) |
| Foundation & Flooring |
Layout: Dual-row grille configuration. Materials: 30x4mm flat bar combined with ⌀8mm twisted steel. Quantity: 24 individual grille sections. Extraction Path: Ground-level (Sidewall draft optional). |
| Primary Entrance |
Aperture: 4,000 mm (W) × 4,600 mm (H). Design: 4-leaf folding sheet metal structure. Glazing: Square tempered safety glass. Core: EPS Insulation. Options: Electric rolling shutter available. |
| Service Access |
Quantity: 2 Units. Size: 800 mm × 2,000 mm. Safety: Fitted with pressure-relief latches and viewports. |
|
|
